Photo of the day: K8 Ultra-U Pro and PX925XE Pro-R motherboards in our lab
We are now testing new motherboards from Albatron: K8 Ultra-U Pro and PX925XE Pro-R.
The first board bases on ULi M1689 chipset, supports AMD Athlon 64/Sempron (Socket 754) processors, features up to 800 MHz HyperTransport bus (up to 3.2 GB/s duplex throughput). More features include Winbond Super I/O W83627THF controller, Realtek ALC655 audio codec, Realtek RTL8201CL LAN, 2 x sockets for up to 2GB of DDR266-DDR400 SDRAM (with or without ECC), 1 x AGP (1.5V only), 4 x PCI, 2 x IDE (Ultra ATA 66/100/133; up to 4 devices), 2 x USB headers (8 x USB), SATA. Back-panel interfaces are: PS/2 keyboard and mouse, LPT, 2 x COM, 4 x USB, audio connectors.
 |
 |
The second board bases on i925XE+ICH6R chipset bundle, supports Pentium 4 Prescott (Socket 775), 800/1066 MHz FSB. It has the same Winbond Super I/O W83627THF controller, ALC880 audio codec. More features include Broadcom BCM5789 Gbit LAN and VIA VT6105 Mbit LAN, up to 4GB of DDR2-400/DDR2-533 (the X model supports non-ECC, while the XE model works with both ECC and non-ECC modules), according to the press release, no more than 3.2-3.5 GB will be available anyway. There is also 1 x PCI Express x16, 2 x PCI Express x1, 3 x PCI (PCI 2.3), IrDA 1.0 SIR, 2 x IDE (Ultra ATA 66/100/133 DMA, PIO), RAID (0, 1, 0+1, JBOD), 4 x SATA (RAID 0/1).
Back-panel connectors: PS/2 keyboard and mouse, 2 x COM, 1 x LPT, audio, 2 x LAN, 4 x USB.
