Eight layers of 3Dlabs VP870

For the first time we´ve been given a chance to see PCB layers themselves. They can be seen on the 3Dlabs VP870 professional graphics card.

We published photos of VP870 yesterday, and today we present the fragment of its PCB for you to see all the 8 layers through the unvarnished window.
