AOpen AX4SG/P and MX4SG: new Springdale-based motherboards
AOpen offered specifications of new Springdale-based motherboards for Pentium 4 with 400/533/800MHz FSB and dual-channel DDR400. AX4SG/P models are ATX, MX4SG — Micro-ATX.
The AOpen AX4SG series includes all variants of i865 (Springdale) chipsets: 865G, 865P and 865PE. Brief specs are posted in the tables below.
AX4SG/P (ATX) series
|
Model |
AX4SG Max |
AX4SG WLAN |
AX4SPE Max |
AX4SP-N |
AX4SPE-N |
AX4SP-G |
AX4SPE-GN |
|
Chipset |
Intel 865G,
ICH5R |
Intel 865G
ICH5R |
Intel 865PE,
ICH5R |
Intel 865G, ICH5 |
Intel 865PE, ICH5 |
Intel 865P, ICH5 |
Intel 865PE, ICH5 |
|
FSB, MHz |
800/533 /400 |
800/533 /400 |
800/533 /400 |
533/400 |
800/533 /400 |
533/400 |
800/533 /400 |
|
Graphics |
AGP 8X |
AGP 8X |
AGP 8X |
AGP 8X |
AGP 8X |
AGP 8X |
AGP 8X |
|
Audio |
AC’97 |
AC’97 |
AC’97 |
AC’97 |
AC’97 |
AC’97 |
AC’97 |
|
DDR memory |
400/333 /266 |
400/333 /266 |
400/333 /266 |
333/266 |
400/333 /266 |
333/266 |
400/333 /266 |
|
Serial ATA |
X 4 |
X 2 |
X 4 |
X 2 |
X 2 |
X 2 |
X 2 |
|
RAID (0, 1) |
RAID 0, 1 Silicon Image |
RAID 0, 1 Silicon Image |
RAID 0, 1 Silicon Image |
X |
X |
X |
X |
|
LAN |
Broadcom
Gigabit PCI LAN |
Broadcom Gigabit PCI LAN |
Broadcom Gigabit PCI LAN |
Broadcom 10/100Mbps LAN |
Broadcom 10/100Mbps LAN |
X |
RealTek 10/100Mbps LAN |
|
IEEE1394 |
X 2 |
X |
X 2 |
X |
X 2 |
X |
X |
|
Wireless |
X |
Bluetooth & Wireless LAN |
X |
X |
X |
X |
X |
MX4SG Micro-ATX series
|
Model |
MX4SG-N |
MX4SG-L |
MX4SGI-N |
MX4SGI-L |
|
Chipset |
Intel 865G, ICH5 |
Intel 865G ICH5 |
Intel 865G, ICH5 |
Intel 865G, ICH5 |
|
FSB, MHz |
800/533/400 |
800/533/400 |
800/533/400 |
800/533/400 |
|
Graphics |
AGP 8X |
AGP 8X |
AGP 8X |
AGP 8X |
|
Int. VGA |
V |
V |
V |
V |
|
Memory |
DDR400/333/266 |
DDR400/333/266 |
DDR400/333/266 |
DDR400/333/266 |
|
Serial ATA |
X 2 |
X 2 |
X 2 |
X 2 |
|
LAN |
Broadcom 10/100Mbps LAN |
Broadcom Gigabit PCI LAN |
Intel GigabitLAN |
Intel 10/100MbpsLAN |
